LOWARA-16L-X 16 mm Mechanical Seal for Lowara SV Series Pumps

Seal Reference	LOWARA-16L-X
Compatible Pump Brand	Lowara
Seal Construction	Single-spring mechanical seal
Size Information	16 mm; verify seat dimensions and working length
Replacement Application	Selected Lowara SV-series configurations
Before Ordering	16L-X reference, full SV pump designation and seat profile

Product Details

Product Name	LOWARA-16L-X 16 mm Mechanical Seal for Lowara SV Series Pumps
Supplier	Hong Teng
Model / Reference	LOWARA-16L-X
Compatible Equipment	Selected Lowara SV-series configurations
Seal Construction	Single-spring mechanical seal
Size Selection	16 mm; verify seat dimensions and working length
Key Identification Points	16L-X reference, full SV pump designation and seat profile
Installation Data	Shaft or sleeve diameter; stationary-seat outside diameter and thickness; installed working length
Materials	Confirm seal-face, elastomer and metal materials against the application and quotation
Operating Conditions	Provide the fluid, temperature, pressure and shaft speed; operating limits depend on the supplied configuration
Required Enquiry Details	Pump nameplate, complete old-seal photos, dimensions with units and quantity

Product Description

The LOWARA-16L-X 16 mm mechanical seal is a single-spring replacement reference for selected Lowara SV-series pump configurations. Match the full pump designation and removed seal before confirming an order; the SV family name does not identify every seat and installation arrangement.

Pay particular attention to the complete 16L-X reference, the rotating assembly length and the separate stationary-seat profile. Photograph the spring end and sealing face, then provide the shaft or sleeve measurement and the installed working length.

See the Lowara pump mechanical seal range for other references. A separate 8731851 12/16 mm seal listing is available for comparison, but a matching nominal size is not sufficient to substitute it for 16L-X.

Our Lowara replacement mechanical seal guide helps organize the nameplate, old-part photographs and measurements for an identification enquiry.

Compatibility notice: Lowara and related reference numbers identify the intended application only. This replacement is independently supplied by Hong Teng and is not an original Lowara part.

Application

Applications

Repair and replacement of selected Lowara SV-series pumps with a confirmed LOWARA-16L-X 16 mm seal fit.
Spare-part matching from an existing 16L-X assembly or an installation drawing for the relevant pump version.

How to Confirm the Correct Replacement

Pump designation	Send the complete SV pump nameplate, including model suffixes and product code.
Seal reference	Include all 16L-X markings or supporting documentation, plus the complete removed seal.
Installation geometry	Confirm the 16 mm fit, stationary-seat diameter and thickness, and installed working length.
Material selection	State the fluid, temperature and other operating conditions for the supplied configuration.

Selection Questions

Does LOWARA-16L-X fit every SV pump with a 16 mm shaft?
No. Compare the full pump designation, seat and installation length for the particular version.

Is LOWARA-16L-X the same as the LOWARA-22-X product?
Do not treat the two references as substitutes. This page is for the 16 mm 16L-X listing; check the correct reference and dimensions for the equipment.

Important: Confirm the complete rotating and stationary parts, installation dimensions and material configuration before ordering. The listing does not establish interchangeability with another reference.

Send the pump nameplate, seal photos and dimensions for a quotation.

Product Reference Images

Images help compare the existing parts; they do not confirm material grades or final fit.
